1000V Voltage Rating Servo Motor Connector with Wide Temperature Range -40℃ to +105℃ and Multiple Pin Configurations (4PIN to 17PIN)

Product Description: Domestic servo cable connector IX-10P plug 6FX2003-0DE61 SM-12T cover 6FX3002-2CT20 6FX2003-0SL12

The Servo Motor Connectors are essential components designed to ensure reliable and efficient connections in various industrial automation applications. Engineered to support the demanding requirements of modern servo motor systems, these connectors are compatible with a wide range of servo motors, including AC Brushless Servo Motor, AC Servo Drive, and High Torque DC Servo Motor configurations. Their robust design and versatile functionality make them indispensable in precision motion control environments where performance and durability are critical.

One of the standout features of these Servo Motor Connectors is their impressive voltage rating of 1000V. This high voltage capacity ensures that the connectors can handle the power demands of heavy-duty servo motors without compromising safety or performance. Whether it's a high torque DC servo motor used in robotics or an AC brushless servo motor employed in CNC machines, these connectors provide a stable and secure electrical connection, minimizing the risk of power loss or electrical faults.

The connectors come in multiple pin configurations, offering great flexibility to suit different application needs. Available in 4-pin, 6-pin, 8-pin, 12-pin, and 17-pin varieties, these connectors can accommodate various wiring requirements, making them suitable for a broad spectrum of servo motor setups. The choice of pin number allows engineers and technicians to select the perfect connector that matches the complexity and control signals needed by their specific servo motor systems, whether it’s a simple AC servo drive or a more complex high torque DC servo motor arrangement.

Designed specifically as servo motor connectors, these components excel in providing secure and reliable connections between servo motors and their driving electronics. The connector type ensures compatibility with standard servo motor interfaces, helping to streamline installation and maintenance processes. This compatibility reduces downtime and enhances overall system efficiency, which is crucial in industrial automation where consistent uptime is vital for productivity.

Durability is another key attribute of these Servo Motor Connectors. They are engineered to operate effectively across a wide temperature range, from -40℃ to +105℃. This broad operating temperature range means the connectors can withstand harsh industrial environments, including extreme cold and high heat conditions, without degradation in performance. Such resilience is important for applications involving AC brushless servo motors or high torque DC servo motors that may operate in diverse environmental settings, from refrigerated warehouses to high-temperature manufacturing floors.

In industrial automation, the reliability of connections directly affects the precision and control of servo motor-driven systems. These Servo Motor Connectors contribute to the seamless operation of automated machinery by ensuring consistent signal transmission and power delivery. Their robust construction and high voltage rating make them ideal for use with AC servo drives, where precise motor control is essential for maintaining accuracy and efficiency in automated processes.

Moreover, these connectors facilitate easy integration with various servo motor types and control systems, making them a versatile choice for engineers designing or upgrading automation solutions. Whether implementing a new AC brushless servo motor setup, enhancing an existing AC servo drive system, or deploying a high torque DC servo motor for heavy-duty applications, these connectors provide the dependable connections required for optimal performance.

In summary, the Servo Motor Connectors stand out as high-quality, versatile, and durable components tailored for the rigorous demands of industrial automation. Their 1000V voltage rating, multiple pin configurations, and wide operating temperature range of -40℃ to +105℃ make them perfect for connecting AC brushless servo motors, AC servo drives, and high torque DC servo motors. By ensuring reliable electrical connections, these connectors play a crucial role in enhancing the efficiency, precision, and longevity of servo motor systems across various industrial applications.

Features:

• Product Name: Servo Motor Connectors
• Voltage Rating: 1000V
• Gender Options: 8PIN, 4PIN, 6PIN, 12PIN, 17PIN
• Insulation Resistance: Available for 6PIN and 7PIN configurations
• Termination Type: Crimp and Solder
• Mounting Type: Panel Mount and Cable Mount
• Compatible with High Torque DC Servo Motor applications
• Suitable for Electro Hydraulic Servo systems
• Ideal for AC Brushless Servo Motor connections

Technical Parameters:

Applications:

The NO MARK 6FX2003 Servo Motor Connectors are essential components designed to ensure reliable and efficient connectivity for various servo motor applications. Manufactured in China and certified with CE and ISO9001 standards, these connectors are crafted from high-quality metal and plastic materials, offering durability and excellent performance in demanding environments. With a voltage rating of 1000V and contact plating options including silver and gold-plated pins, these connectors guarantee optimal electrical conductivity and corrosion resistance, making them ideal for both industrial and commercial uses.

These servo motor connectors are perfectly suited for high torque DC servo motor setups, where precision and reliability are paramount. Their compatibility with wire gauges ranging from 18-24 AWG and even larger diameters from AWG 3 to 12 makes them versatile for various cable specifications. Whether you are working with AC brushless servo motors or high torque DC servo motors, the 6FX2003 connectors provide a secure and stable connection, ensuring seamless power transmission and signal integrity.

In industrial automation, these connectors are widely used in robotics, CNC machinery, and automated assembly lines where servo motors play a critical role in motion control. The robust construction of the connectors helps withstand vibrations and harsh operating conditions commonly found in factory floors. Additionally, their compact design and secure locking mechanism make them suitable for applications requiring frequent maintenance or replacement.

For manufacturers and distributors, NO MARK offers a minimum order quantity of 100 pieces with a supply ability of 1000 pcs per day, ensuring timely availability for large-scale projects. The product is packaged securely in carton boxes to protect against damage during transit. With a delivery time of just 1-3 working days and flexible payment terms including T/T and PayPal, customers can expect a smooth procurement process.

Overall, the NO MARK 6FX2003 Servo Motor Connectors are an excellent choice for engineers and technicians seeking reliable connectivity solutions for high torque DC servo motor and AC brushless servo motor applications. Their high-quality build, certification credentials, and adaptable design make them indispensable components in modern servo motor control systems.

Customization:

Our Servo Motor Connectors, model number 6FX2003, are designed for high performance and reliability, suitable for High Torque DC Servo Motor, AC Brushless Servo Motor, and Brushless Servo Motor applications. Manufactured in China under strict quality control, these connectors are CE and ISO9001 certified to ensure compliance with international standards.

We offer product customization services with a minimum order quantity of 100 units. The connectors are available with various pin configurations including 4PIN, 6PIN, 8PIN, 12PIN, and 17PIN, accommodating wire gauges from 18-24 AWG or larger, up to AWG 3-12 diameter. The connectors support a voltage rating of up to 1000V and are made from durable metal and plastic materials to guarantee long-lasting performance.

Each order is carefully packaged in a carton box to protect the products during shipping. We provide a fast delivery time of 1-3 working days and flexible payment terms including T/T and PayPal. Our supply ability reaches up to 1000 pieces per day, ensuring that your production needs are met efficiently.

Trust our Servo Motor Connectors for your High Torque DC Servo Motor, AC Brushless Servo Motor, and Brushless Servo Motor projects, combining quality, customization, and prompt service.

Support and Services:

Our Servo Motor Connectors are designed to ensure reliable and efficient connections in servo motor systems. For technical support, we provide comprehensive assistance including installation guidance, troubleshooting, and maintenance tips to optimize connector performance.

Our support team is equipped to help with compatibility questions, wiring diagrams, and ensuring that connectors meet your specific application requirements. We also offer detailed product documentation, including datasheets and user manuals, to facilitate proper usage.

In addition to technical support, we provide after-sales services such as warranty coverage, repair options, and replacement parts to maintain the longevity of your servo motor connectors. Our goal is to deliver seamless connectivity solutions that enhance the performance and reliability of your servo motor systems.

Packing and Shipping:

Each Servo Motor Connector is carefully packed in anti-static bags to ensure protection against moisture and static electricity during transportation. The connectors are then placed in sturdy cardboard boxes with adequate cushioning materials to prevent any damage from shocks or vibrations.

For bulk orders, the connectors are organized in smaller inner boxes or trays before being packed into larger shipping cartons. All packaging materials are chosen to be environmentally friendly and recyclable.

Shipping is carried out via reliable courier services, with options for expedited or standard delivery based on customer preference. Each shipment is accompanied by a detailed packing list and tracking information to ensure timely and secure delivery to the customer’s location.
