M23 Aviation Plug Servo Motor Connector with Silver Gold-Plated Pins Panel Mount and 12-Pin 17-Pin Options

Product Description:

The Servo Motor Connectors are precision-engineered components designed to ensure reliable and efficient connections in various servo motor applications. These connectors are essential for the seamless integration of AC Servo Drive and DC Servo Motor Drive systems, providing robust electrical performance and durability under demanding operational conditions. Their design accommodates a wide range of servo motor configurations, making them a versatile choice for both industrial and commercial applications.

One of the standout features of these Servo Motor Connectors is their superior contact plating options. The contacts are available with silver plating and gold-plated pins, which significantly enhance conductivity and reduce signal loss. Silver plating offers excellent electrical conductivity and resistance to corrosion, making it ideal for high-frequency signal transmission. Meanwhile, the gold-plated pins provide exceptional resistance to oxidation and wear, ensuring long-lasting, stable connections even in harsh environments. This dual plating option allows users to select the best configuration based on their specific application needs, whether it’s an AC Servo Drive or a DC Servo Motor Drive setup.

In terms of termination, these connectors support both crimp and solder methods, offering flexibility in installation and maintenance. The crimp termination type ensures a secure mechanical and electrical connection, which is quick and reliable for mass production or field installations. Solder termination, on the other hand, provides a strong bond that is ideal for applications requiring enhanced mechanical strength and electrical continuity. This dual termination capability makes the connectors highly adaptable, catering to various wiring preferences and assembly processes.

The operating temperature range of these Servo Motor Connectors is impressively broad, from -40℃ to +105℃. This wide thermal tolerance ensures reliable performance in extreme environmental conditions, from sub-zero cold storage facilities to high-temperature industrial settings. Such resilience is critical for servo motor systems that often operate continuously and under varying thermal stresses. This operating range guarantees that the connectors maintain their integrity and functionality, contributing to the overall reliability of AC Servo Drive and DC Servo Motor Drive systems.

Mounting options for these connectors are thoughtfully designed to enhance installation versatility. They are available in both panel mount and cable mount configurations. Panel mount connectors are perfect for fixed installations on control panels or machinery, providing a stable and secure connection point. Cable mount connectors facilitate flexible wiring solutions, allowing easy integration into cable assemblies and enabling quick disconnects for maintenance or replacement. This adaptability in mounting types ensures that the connectors can fit seamlessly into various system designs and layouts.

Additionally, the Servo Motor Connectors come in multiple gender and pin configurations to meet diverse application requirements. The available options include 4-pin, 6-pin, 8-pin, 12-pin, and 17-pin connectors. This range of pin counts allows for customization based on the complexity and number of signals or power lines needed in a servo motor drive system. Whether you are working with a simple DC Servo Motor Drive or a more complex AC Servo Drive setup, these connectors provide the necessary interface to facilitate efficient communication and power transfer.

In summary, these Servo Motor Connectors are engineered to deliver high performance, durability, and flexibility for servo motor drive applications. Their silver and gold-plated contacts ensure excellent conductivity and long-term reliability. The availability of crimp and solder termination types caters to various assembly needs, while the wide operating temperature range guarantees functionality in extreme conditions. With both panel mount and cable mount options, as well as multiple pin configurations, these connectors are adaptable to a wide range of AC Servo Drive and DC Servo Motor Drive systems. Choosing these connectors means investing in quality, reliability, and versatility for your servo motor connectivity needs.

Features:

• Product Name: Servo Motor Connectors
• Compatible Wire Gauge: 18-24 AWG or more, AWG 3-12 Diameter
• Model Name: 6FX2003
• Available Genders: 8-pin, 4-pin, 6-pin, 12-pin, 17-pin options
• Contact Plating Options: Silver and Gold-plated pins
• Material: Durable Metal and Plastic construction
• Designed for Brushless Servo Motor applications
• Ideal for use with AC Servo Drive systems
• Compatible with AC Servo Motor Driver units

Technical Parameters:

Applications:

The NO MARK 6FX2003 Servo Motor Connectors are expertly designed to meet the demanding requirements of AC Brushless Servo Motor applications. Manufactured in China and certified with CE and ISO9001, these connectors guarantee high reliability and quality, making them an ideal choice for professionals working with Brushless Servo Motors in various industrial and automation settings.

These connectors are particularly suited for AC Brushless Servo Motor systems that require stable and efficient electrical connections. With a current rating ranging from 1A to 10A and a voltage rating of up to 1000V, the 6FX2003 model supports a wide variety of servo motor configurations, ensuring optimal performance under different load conditions. Their ability to operate within a temperature range of -40℃ to +105℃ makes them versatile for use in harsh environments where temperature fluctuations are common.

Due to their flexible wire gauge compatibility (18-24 AWG or even larger diameters such as 3-12 AWG), these connectors accommodate various cable sizes, enhancing their usability in diverse AC Brushless Servo Motor setups. The mounting options, including panel mount and cable mount, further expand their application scenarios, allowing easy integration into control panels, industrial machinery, robotics, and automated production lines.

The 6FX2003 connectors are ideal for applications that demand quick and secure connections, including servo drives, CNC machinery, packaging equipment, and precision motion control systems. Their robust construction ensures long-lasting durability, essential for continuous operation in manufacturing plants and assembly lines. The packaging in carton boxes guarantees safe delivery, and with a supply ability of 1000 pieces per day, orders can be fulfilled promptly, with a typical delivery time of 1-3 working days.

For businesses and integrators, the minimum order quantity of 100 pieces, combined with convenient payment terms such as T/T and PayPal, ensures a smooth procurement process. Whether you are replacing connectors in existing Brushless Servo Motor setups or designing new systems, the NO MARK 6FX2003 Servo Motor Connectors offer a reliable and efficient solution to maintain superior connectivity and performance.

Customization:

Our Servo Motor Connectors, model number 6FX2003, are designed to meet the highest standards of quality and performance. Manufactured in China and certified by CE and ISO9001, these connectors are ideal for use with AC Brushless Servo Motors, Hydraulic Brake Motors, and Electro Hydraulic Servo systems. We offer customization services to accommodate various connector types including 8pin, 4PIN, 6PIN, 12PIN, and 17PIN configurations, ensuring compatibility with your specific application.

These connectors support a voltage rating of up to 1000V and operate reliably within a temperature range of -40℃ to +105℃. Current ratings vary from 1A to 10A and beyond, making them suitable for a wide range of power requirements. Our supply ability reaches up to 1000 pieces per day, with a minimum order quantity of 100 units to fulfill your production needs efficiently.

Packaging is done securely in carton boxes to protect the connectors during shipping. Delivery time is fast, typically within 1-3 working days. We accept flexible payment terms including T/T and PayPal to facilitate smooth transactions. Choose NO MARK brand Servo Motor Connectors for durable, high-quality connectivity solutions tailored to your AC Brushless Servo Motor, Hydraulic Brake Motors, and Electro Hydraulic Servo applications.
