Product Details:
Payment & Shipping Terms:
|
| Color: | Blue | Size: | See Detail Drawing |
|---|---|---|---|
| Material: | Use New Plastic And Metail Parts | Data: | Can Build Base On Buyer Detail Asked |
| High Light: | pcb screw terminal block connector,pcb mount screw terminal block |
||
Material:
Pitch: 3.81mm
Poles: 2P-24p, can assembly any poles
Screw: M2.5 Steel Zinc plated
Contact: Phosphor bronze Ni plated
Wire cage: Brass Ni plated or steel zinc plated.
Housing: PA66 UL 94-0
Electrical:
Rated voltage: 300V
Rated current: 15A
With standing voltage: AC2000V/1min
Wire range: 22-12 AWG
Mechanical:
Temperature range: -30℃ ~ +105℃
Max soldering: +250℃ for 5sec.
Torque: 0.4Nm(3.5 lb in)
Strip length: 4.5-5mm
contact daisyzhou_003 at 163.com
We are manufacturing a variety of Terminal blocks, mainly producing Pluggable terminal block, Barrier terminal block, Spring Terminal block, Screw terminal block, Feed through Terminal block. We also have the certifications of UL,VDE etc. OEM&ODM are warmly welcomed.Any question, please contact us freely.
