Product Details:
Payment & Shipping Terms:
|
| Operating Temperature: | -40℃ To +105℃ | Connector Type: | Servo Motor |
|---|---|---|---|
| Current Rating: | 16A-30A | Contact Plating: | Gold/Silver |
| Gender: | 9PIN | Insulation Resistance: | 1000 M |
| Number Of Contacts: | 9pin | Wire Gauge: | 18-24 AWG Or More AWG6.0-6.5 Dia |
| High Light: | 30A Brushless Servo Motor,Silver Contact Plating Brushless Servo Motor,9PIN Servo Motor Connector |
||
The Servo Motor Connectors are a vital component in the realm of industrial automation, designed to seamlessly integrate with the sophisticated control systems that are the backbone of modern machinery. These connectors are specifically engineered to cater to the high-performance demands of Brushless Servo Motors and AC Servo Drives, ensuring reliable and efficient power and signal transmission.
With an exceptional Insulation Resistance of 1000 MΩ, these connectors guarantee an outstanding level of electrical integrity, preventing any leakage currents that could potentially disrupt the precise functioning of servo systems. This high insulation resistance is crucial in maintaining the accuracy and responsiveness of Brushless Servo Motors, which are integral to a wide array of industrial applications, from robotics to CNC machinery.
The versatility of the Servo Motor Connectors is reflected in their Termination Type, which accommodates both Crimp and Solder techniques. This dual approach to cable termination provides users with the flexibility to choose the most suitable method for their specific application, whether it be for a permanent, robust connection via soldering or for a more adaptable and serviceable crimped connection.
Moreover, these connectors are designed to support a broad range of wire gauges, from 18-24 AWG, and even larger wires up to AWG6.0-6.5 Dia. This feature makes them highly adaptable and capable of handling the diverse wiring requirements found in complex industrial settings. The robust construction ensures a secure connection even for the heaviest gauge wires, which is essential for transmitting the high currents needed to drive powerful Brushless Servo Motors.
The number of contacts within these connectors is standardized at 9 pins, which allows for a comprehensive interface between the servo motor and the AC Servo Drive. The contact array is carefully designed to accommodate all necessary power, signal, and feedback connections, ensuring that the Brushless Servo Motor operates at peak performance levels, with precise speed and position control.
One of the most critical aspects of these connectors is their application within Industrial Automation. The combination of high insulation resistance, flexible termination options, wide wire gauge compatibility, and a sufficient number of contacts makes these connectors an indispensable component in the seamless operation of automated systems. They ensure that the Brushless Servo Motors function reliably, responding accurately to the commands sent from the AC Servo Drive. This reliability is paramount in applications where precision and repeatability are key, such as in assembly lines, automated material handling, and complex manufacturing processes.
In conclusion, the Servo Motor Connectors are a fundamental component in connecting Brushless Servo Motors to AC Servo Drives within the field of industrial automation. Their robust design, featuring high insulation resistance, flexible termination types, compatibility with a wide range of wire gauges, and a sufficient number of contacts, ensures that they can meet the high demands placed upon them by modern automated systems. The reliability and versatility of these connectors make them a critical element in the performance and efficiency of advanced machinery, contributing to the overall productivity and success of industrial enterprises.
| Attribute | Specification |
|---|---|
| Application | Industrial Automation, Electro Hydraulic Servo, AC Servo Drive |
| Connector Type | Servo Motor |
| Current Rating | 16A-30A |
| Wire Gauge | 18-24 AWG Or More AWG6.0-6.5 Dia |
| Insulation Resistance | 1000 MΩ |
| Termination Type | Crimp/Solder |
| Voltage Rating | 240V |
| Material | Metal/Plastic |
| Contact Plating | Gold/Silver |
| Number of Contacts | 9pin |
The NO MARK MX-09 servo motor connectors are a high-quality solution for a wide range of applications that require reliable and durable connections. Manufactured in China and boasting certifications such as CE and ISO9001, these connectors are designed to meet the stringent standards of various industries. With a minimum order quantity of 100 units and a robust supply ability of 1000 pcs/day, the NO MARK MX-09 connectors can cater to both small-scale projects and large-volume needs.
Engineered to support wire gauges ranging from 18-24 AWG or more with a diameter of 6.0-6.5mm, these connectors ensure compatibility with a variety of cable sizes, enabling versatility across applications. The gold or silver contact plating is a testament to their commitment to quality, ensuring optimal conductivity and resistance to corrosion. The operating temperature range of -40℃ to +105℃ allows these connectors to function effectively in extreme conditions, making them suitable for use in harsh environments.
NO MARK MX-09 connectors are an ideal choice for connecting brushless servo motors, AC brushless servo motors, and high torque DC servo motors in various scenarios. Whether these motors are utilized in industrial automation, robotics, CNC machinery, or aerospace applications, the connectors provide a secure and stable connection. The panel mount and cable mount options offer flexibility for different mounting preferences, thus simplifying the integration process for equipment manufacturers and maintenance technicians.
Packaging details for the NO MARK MX-09 connectors include a sturdy carton box to ensure the product's integrity during shipping. With a delivery time of just 1-3 working days and payment terms that accommodate T/T and PayPal, acquiring these connectors is both swift and convenient for customers. These features, combined with their robust design, make the NO MARK MX-09 servo motor connectors a reliable and efficient choice for a myriad of application occasions and scenarios where precision and durability are paramount.
Brand Name: NO MARK
Model Number: MX-09
Place of Origin: China
Certification: CE, ISO9001
Minimum Order Quantity: 100
Price: NA
Packaging Details: Carton box
Delivery Time: 1-3 working days
Payment Terms: T/T, PayPal
Supply Ability: 1000 pcs/day
Operating Temperature: -40℃ To +105℃
Wire Gauge: 18-24 AWG Or More AWG6.0-6.5 Dia
Name: Fast Connector
Connector Type: Servo Motor
Gender: 9PIN
Our Fast Connector is ideal for Electro Hydraulic Servo systems, providing a reliable connection for both AC Servo Drives and DC Servo Motor Drives. Engineered for precision and durability, this 9PIN Servo Motor Connector ensures optimal performance in a variety of industrial applications.
Our Servo Motor Connectors are designed to ensure a reliable and efficient connection for your servo motor applications. With a focus on durability and performance, our connectors offer the following technical support and services:
Technical Documentation: Comprehensive datasheets, installation guides, and specifications are available for all connector models to assist with product understanding and proper usage.
Installation Assistance: Detailed instructions for the correct installation of your Servo Motor Connectors are provided, ensuring optimal performance and longevity of the product.
Compatibility Guidance: Our technical support team can help you determine the most suitable connectors for your specific servo motors, considering factors such as voltage, current, and environmental conditions.
Troubleshooting Support: In the event of performance issues, our skilled technicians offer troubleshooting assistance to diagnose and resolve connector-related problems promptly.
Product Customization: For applications that require unique specifications, we offer custom connector solutions tailored to meet your exact requirements.
Quality Assurance: All of our Servo Motor Connectors undergo rigorous testing to meet high-quality standards, ensuring reliability and safety in operation.
Warranty Service: We stand behind the quality of our connectors with a warranty that covers defects in materials and workmanship, providing peace of mind and protection for your investment.
Our commitment to excellence in both our products and support services ensures that you can rely on our Servo Motor Connectors for superior performance in all your applications.
Product Packaging for Servo Motor Connectors:
Each set of Servo Motor Connectors is carefully packaged in an anti-static bag to prevent electrostatic discharge damages. The connectors are then placed in a custom-fit foam insert that ensures they remain secure during transportation. The foam insert, along with the connectors, is encased in a sturdy cardboard box that is labeled with the product information, handling instructions, and a barcode for easy inventory management.
Shipping Information for Servo Motor Connectors:
All orders of Servo Motor Connectors are dispatched within 2 business days via our standard courier services. The connectors are shipped in their protective cardboard boxes and consolidated into a larger shipping carton to ensure maximum protection. Fragile stickers are affixed to the outer carton to remind carriers to handle the goods with care. Tracking information will be provided upon shipment so that customers can monitor the delivery status of their order.
